Techtron
Battery Current Display Solar Charge Controller
Battery Current Display Solar Charge Controller
Couldn't load pickup availability
Product Information:
Material: ABS
Neutral Cattle Card Packaging Box Size: 20.5*10.8*6.5cm
Specification: M30
System voltage: 12V/24V (lead-acid battery) /12.8V four strings of lithium iron phosphate batteries
Maximum charge and discharge current: 30A
Maximum input power of solar panel: 18V-24V-380W /36V-48V-760W
Load working time setting: 1-24 hours. Adjustable
Charging mode: PWM
Overvoltage protection: 17V/34V
Fully disconnected: 13.8V/27.6V adjustable
Undervoltage disconnection: 10.8V /21.6V adjustable
Over-discharge recovery voltage: 12.2V adjustable
No-load loss: S 20mA
Wire specification: ≤7# AWG (16mm)
Working environment temperature: -25C- -55C
Packing List:
Plastic charge controller x1
